Hydraulic distributors HYDRONT
-
Monoblock hydraulic distributors series Р1М- Rated flow: 25 to 160 l / min
- Maximum pressure: 250 and 315 bar
- Maximum pressure at port T: 10 and 25 bar
- Internal leaks: 3 to 5 cm3 / min
- Ambient temperature: -60 ° ... + 50 °С
- Working fluid temperature (at NBR seal): -40 ° ... + 80 °С
- Working fluid temperature (at VITON seal): -30 ° ... + 100 °С
- Viscosity of working fluid: 12-1300
- Maximum pollution level in accordance with GOST 17216 (no coarser): 14
-
Sectional hydraulic distributors series Р1C- Nominal flow rate: 45 to 400 l / min
- Мaximum pressure: 315 bar
- Maximum pressure for series circuit: 0 to 315 bar
- Maximum pressure at port T: 10 and 25 bar
- Number of sections: 1-10 and 1-12
- Internal leaks: 3, 5 and 25 cm3 / min
- Ambient temperature: -60 ° ... + 50 ° С
- Working fluid temperature (at NBR seal): -40 ° ... + 80 ° С
- Working fluid temperature (at VITON seal): -30 ° ... + 100 ° С
- Viscosity of working fluid: 12-1300
- Maximum pollution level in accordance with GOST 17216 (no coarser): 14
-
Sectional hydraulic distributors (LS) series Р1Ф- Nominal flow rate in pressure line P with compensator: 80, 120 and 230 l / min
- Nominal flow rate in working lines A and B: 50, 90 and 160 l / min
- Maximum pressure in the pressure line P: 300 bar
- Maximum pressure in working lines A and B: 300 and 350 bar
- Maximum back pressure in the T line, mechanical and electro-hydraulic control: 10 bar
- Maximum back pressure in the T line, hydraulically controlled: 30 bar
- Internal leaks of the working section without secondary valves: 6.5, 9 and 12 cm3 / min
- Internal leaks of the working section with secondary valves: 11.5, 14 and 17 cm3 / min
- Number of sections: 1-10 and 1-12
- Ambient temperature: -45 ° ... + 50 ° С
- Fluid temperature (NBR seals): -30 ° ... + 80 ° C
- Working fluid temperature (VITON seals): -30 ° ... + 100 ° C
- Viscosity of working fluid: 12-400
- Maximum pollution level in accordance with GOST 171216 (no rougher): 12
-
Sectional hydraulic distributors (LS) series Р1К- Nominal flow rate in pressure line P: 150 and 260 l / min
- Nominal flow rate in working lines A and B with compensator: 100 and 200 l / min
- Nominal flow rate in working lines A and B without compensator: 130 and 240 l / min
- Maximum pressure in pressure line P: 315 and 350 bar
- Maximum pressure in working lines A and B: 315 and 420 ba
- Maximum back pressure in the return line T: 25 bar
- Maximum back pressure in the drain line L: 2.5 bar
- Internal leaks without secondary valves: 16 and 20 cm3 / min
- Internal leaks with secondary valves: 21 and 25 cm3 / min
- Number of sections: 1 - 10
- Ambient temperature: -45 ° ... + 60 ° C
- Fluid temperature (NBR seals): -30 ° ... + 80 ° C
- Working fluid temperature (VITON seals): -30 ° ... + 100 ° C
- Viscosity of working fluid: 12-400
- Maximum pollution level in accordance with GOST 17216 (no rougher): 12
